Materail: Food grade POM
Seal rubber material: EPDM
Metal screw material: SUS304
Maximum inlet water pressure: 1.2Mpa
Temperature range :0 to 60 °C
Test life: water hammer 12Mpa water cycle+EPDM membrane seal with one hundred thousand times
*Push-fit technology
*Quick disconnection without the need for tools
*High chemical resistance
*Not suitable for air or insert gases
Please contact us at info@happie-water.com for the water fittings catalog.
Or please visit our Alibaba store for more information:
happiewater.en.alibaba.com
Size range
1/4 inch , 5/16 inch , 3/8inch ,1/2 inch, 12mm quick fittings for option
| PARTS-NO | TUBE O.D IN | TUBE O.D OUT | TUBE O.D OUT |
| HP017-A | 1/4 | 1/4 | 1/4 |
| HP017-B | 3/8 | 3/8 | 3/8 |
| HP017-C | 3/8 | 1/4 | 1/4 |
| HPY050505 | 5/16 | 5/16 | 5/16 |
| HPY030303 | 6mm | 6mm | 6mm |
| HPY050505B | 8mm | 8mm | 8mm |
| HPY101010 | 10mm | 10mm | 10mm |
| HPY121212 | 12mm | 12mm | 12mm |
